In this episode of Product of the Week, Robin takes a look at the PicoScope 2205A, a compact USB oscilloscope from Pico Technology. With two analog channels, 25 MHz bandwidth, and 8-bit resolution, the PicoScope brings waveform viewing and signal analysis to your computer. Use your laptop as the display, save space on your workbench, and take your test equipment out to your next project.
Robin explores the hardware, PicoScope software, and practical uses for desktop testing and field work. From checking PWM outputs and sensor signals to comparing circuit inputs and outputs, this episode covers how a portable oscilloscope fits into your electronics toolkit.
📌 Chapters:
0:00 – Introducing the PicoScope 2205A
0:33 – What Is a USB Oscilloscope?
1:06 – Compact Design and Portability
1:42 – Two Channels, Bandwidth and Resolution
2:14 – Input Range and Supplied Probes
2:33 – PicoScope Software and USB Setup
3:18 – Circuit and Microcontroller Debugging
4:05 – Using the PicoScope as a Travel Scope
4:48 – Final Thoughts
💬 Join the Conversation!
Tell us in the comments below which circuit you’d test with the PicoScope 2205A.
💡 Key Features:
Two analog input channels
25 MHz bandwidth
8-bit vertical resolution
Up to 200 MS/s real-time sampling on channel A, or 100 MS/s per channel with both active
USB connection and power
Computer-based waveform viewing, zooming, and spectrum analysis
Supplied oscilloscope probes
